Belle HPX01S Bulldog Petrol Bulldog Hydraulic Power Pack Compact Efficient for On-Site Applications

An efficient. portable on site power source that is 12% more compact but with the same market leading performance. Comes with integrated Power On-Demand (POD) system and more powerful engine than the standard market equivalent.

Features:

Compact Design: 12% more compact than previous models while maintaining market-leading performance. Easily transportable in estate cars and small vans.
Tilt-Back Protection Frame: Facilitates simple routine maintenance.
Optional Tool Tray: Clip & Go removable tool tray available for convenient storage of hydraulic breakers and breaker steel.
Powerful Engine: Equipped with a more powerful engine compared to standard market equivalents.
Protected Oil Filler: Features a fully protected oil filler with a retaining chain.
Integrated POD System: Power On Demand (POD) system reduces carbon emissions and cuts fuel usage by 50%.
Recoil Protection System: Ensures enhanced safety during operation.
Low Oil Cut-Out: Protects tools and system pump with low engine and hydraulic oil cut-out.
Durable Construction: Rigid steel chassis and protection frame designed to prevent component damage.
Convenient Hose Management: Hose storage and lifting-eye integrated into the protection frame. with fitted wheels for easy on-site transportation.
Removable Hose Set: Supplied with a removable braided Siamese hose set featuring high-quality non-drip face couplings. pre-filled with hydraulic oil. Hose sets are easy to replace and aid in transportation and storage.
Versatile Compatibility: Suitable for use with Altrad Belle hydraulic breakers (BHB 25X. BHB 27X. BHB 12. BHB 23. BHB 25 & BHB 27) and hydraulic submersible pumps.
Customizable Appearance: Available in customer-selected colors.

Product Specification:

Part no: HPX01S
Barcode: 5031403034922
Model: Bulldog Honda GX270 Petrol
Engine Power: 8.6 / 6.3 (Hp) - (kW)
Hose Length: 6.75 (m)
Pressure: 140 (bar)
Flow: 20 (l/min)
Oil Tank Capacity: 5.6 (Litre)
Fuel Tank Capacity: 6.0 (Litre)
Dimensions W x L x H: 515 x 705 x 620 (mm)
Weight: 59.5 (Kg)

**images for illustrative purposes only please refer to description and specification for full details of product**
